Top Driven Bottom Discharge Centrifuge
Top Driven Bottom Discharge Centrifuge
- Top Driven Bottom Discharge For Uses In Dexroth Plant In Starch Unit.
- Top Driven Bottom Discharge Centrifuge For Vertical High Speed In Basket .
- Scrapper Unit & Brake Arraignment With Pneumatic Operated.
- Control Panel In Tdb Machine
- This Model Is In Copper Sulphate , Magnesium Sulphate , Ferrous Sulphate Are Mainly Used In Scrap Industries Etc.
| Model | Basket Dia mm |
Basket Depth mm |
Capacity Vol Ltrs. Charge Kgs. |
Drive HP | |
|---|---|---|---|---|---|
| 24 TDBD - 4P & 3P | 500 | 300 | 75 | 50 | 5 |
| 36 TDBD - 4P & 3P | 900 | 450 | 180 | 130 | 10 |
| 48 TDBD - 4P & 3P | 1200 | 480 | 220 | 200 | 15 |
